Introduction The trend of future power supply product development is that the space is getting smaller and smaller, and the power is getting larger and larger. Thus, the electronic components used internally also need to follow this trend to iterate; Our company has seized the opportunity, has successfully developed JA, JB short body plug-in bridge products, and has been successfully mass-produced in the market, in the PC power supply, server power supply, TV power supply and other fields have been widely used; JA, JB products are corresponding to 6KBJ, 4KBJ package of the low body design, the foot distance is unchanged, the height is reduced by about 34%, 36%, saving the customer's overall board height, reducing the size of the heat sink, the comprehensive cost has been effectively reduced. For this reason, our industry's first JC new low body package rectifier bridge, foot distance with the existing GBU package, can be used to replace the GBU package. The product has the characteristics of short body, space saving, surge ability, can be widely used in PC power supply, server power supply, TV power supply, LED driver and so on
Features 1.JC packaging using environmental protection materials, in line with RoHS standards
2. Compared with GBU package, JC reduces the height by about 45%, saving space and helping customers flat design
3. Internal package Photo Glass process chip, three layers of passivation protection, stable high temperature characteristics and reliability
4. The product body is reduced, and the corresponding heat sink size of the back lock will also be reduced, reducing the client cost 5. Temperature rise comparison, with the same size heat sink, JC products and GBU products have no significant difference in temperature rise
SPECIFICATION
